Among these Ford Transit backup cameras, my best overall pick is the 2014–2018 roof-mount camera with selectable 720P AHD and 480P CVBS, since it offers a useful resolution choice for compatible displays. The 2020–2022 A-Premium camera is a standout for newer vans, while the third-brake-light kits with monitors suit buyers who want a more integrated setup. The main tradeoffs are model-year and body-style fit, whether a monitor is included, and how much installation work the mounting design requires. Image resolution and weather protection matter too, but they cannot make an incompatible camera fit. Read on for the full breakdown, ranking logic, and buying advice.
Get business pricing on garage and car supplies
- Business-only prices and quantity discounts
- Tax-exempt purchasing
- Multiple users, one account, clear invoices
Complete the kit
Key Takeaways
- Fitment is the first dividing line: the list spans Transit model years from 2012 through 2022, and Transit Connect cameras are separate choices rather than universal Transit replacements.
- The roof-mount 2014–2018 camera ranks first for flexibility: its AHD/CVBS options can suit different compatible display systems, though buyers must confirm which signal their screen accepts.
- Brake-light cameras favor an integrated installation: several options replace or incorporate the high-mounted brake light, while a license-plate or license-light camera follows a different mounting path.
- Monitor bundles reduce parts matching: the 7-inch monitor packages offer a more complete setup, but add cabin hardware and may not be the right choice if a compatible display is already installed.
- Similar-looking 2015–2019 cameras are not automatically interchangeable: listed year ranges, Transit body versions, connectors, and mounting points still need checking before purchase.
| Backup Camera for Ford Transit 150 250 350 (2014-2018), Waterproof Rear View, Night Vision, 720P AHD / 480P CVBS, Roof Mount |  | Best for AHD-Capable Systems | Compatible vehicles: Ford Transit 150, 250, and 350 (2014–2018) | Resolution: AHD 720P / CVBS 480P | Viewing angle: 140 degrees | VIEW LATEST PRICE | See Our Full Breakdown |
| Auto Wayfeng WF 170 CCD Car Reversing Rear View License Plate Backup Camera for Ford Transit Connect |  | Best for Transit Connect Wide-Angle Coverage | Sensor type: 1/4-inch CCD | Resolution: 728 × 512 pixels | TV lines: 520 | VIEW LATEST PRICE | See Our Full Breakdown |
| Backup Camera for Ford Transit 150/250/350/HD 2015-2017 |  | Best OEM-Style Fit | Compatible vehicles: Ford Transit 150, 250, 350, and HD (2015–2017); listing also states 2018–2019 cargo vans | Optical sensor: CMOS infrared | Field of view: 170 degrees | VIEW LATEST PRICE | See Our Full Breakdown |
| Anpher Rear View 170° HD Night Vision Backup Camera for Ford Transit 150/250/350/350HD (2015-2019) |  | Best for Higher-Resolution Video | Compatible vehicles: Ford Transit 150, 250, 350, and 350HD (2015–2019) | Video capture resolution: 1080P | Viewing angle: 170 degrees | VIEW LATEST PRICE | See Our Full Breakdown |
| Compatible with License Light Backup Camera Ford Transit Connect MK6 MK7 2000-2018 HD 1280x720p with 7-inch Monitor |  | Best Complete Kit for Transit Connect | Compatible vehicles: Ford Transit Connect MK6/MK7 (2000–2018 as listed) | Monitor size: 7 inches | Monitor voltage: 12 volts | VIEW LATEST PRICE | See Our Full Breakdown |
| LED Third Brake Light with Backup Camera for 2018-2019 Ford Transit 150/250/350/HD |  | Best Integrated Brake-Light Replacement | Model years: 2018–2019 | Compatible vehicles: Ford Transit 150, 250, 350, and 350 HD | Position: Center | VIEW LATEST PRICE | See Our Full Breakdown |
| High Mount Third Brake Light Backup Camera for Ford Transit 150 250 350 350HD 2014-2018 |  | Best for Wide Rear Coverage | Compatible model years: 2014–2018 | Compatible vehicles: Ford Transit 150, 250, 350, and 350 HD | Optical sensor: CMOS, 1/3 inch | VIEW LATEST PRICE | See Our Full Breakdown |
| IP67 Waterproof Backup Camera for Ford Transit 2012-2015 |  | Best for Older Transit Models | Compatibility: Ford Transit 2012–2015 | Resolution: 720p | Viewing angle: 140 degrees | VIEW LATEST PRICE | See Our Full Breakdown |
| A-Premium Rear View Backup Camera for Ford Transit 2020-2022 |  | Best for 2020–2022 Low-Roof Transits | Model years: 2020–2022 | Compatible vehicles: Transit 150, 250, 350, and 350 HD, low roof | Part numbers: FO1960188, LK4Z19G490B, LK4Z19G490G, LK4Z19G490K, PAC491 | VIEW LATEST PRICE | See Our Full Breakdown |
| Backup Camera for Ford Transit 150 250 350 350HD (2015-2017, 2018-2019) |  | Best Plug-and-Play Replacement for 2015–2019 | Compatible models: Transit 150, 250, 350, and 350 HD (2015–2017); Transit Cargo Van (2018–2019) | Lens angle: 170 degrees | Night vision: Yes | VIEW LATEST PRICE | See Our Full Breakdown |
| Compatible for Ford Transit 150/250/350/350 HD 2015-2020 Brake Light Backup Camera with 7-inch Clip-on Mirror Monitor |  | Best Complete Kit | Compatible model years: Ford Transit 150/250/350/350 HD, 2015–2020 | Monitor size: 7 inches | Monitor voltage: 12 volts | VIEW LATEST PRICE | See Our Full Breakdown |
| GreenYi Rear View Backup Camera for Ford Transit 150/250/350/350HD 2015-2019 |  | Best for Plug-and-Play Replacement | Compatible vehicles: Ford Transit 150/250/350/350HD, 2015–2017; Transit Cargo Van, 2018–2019 | Listed screen size: 7 inches | Voltage: 12 volts DC | VIEW LATEST PRICE | See Our Full Breakdown |
| Backup Camera for Ford Transit 2014-2018 with 140° Wide Angle, IP67 Waterproof, Night Vision, 720P HD |  | Best for 720p Camera-Only Replacement | Compatibility: Ford Transit, 2014–2018 | Field of view: 140 degrees | Resolution: 720p HD | VIEW LATEST PRICE | See Our Full Breakdown |
| Backup Camera for Ford Transit 150/250/350/HD 2015-2017 |  | Best Wide-Angle Camera-Only Pick | Compatibility: Ford Transit 150/250/350/HD, 2015–2017; Cargo Van, 2018–2019 | Field of view: 170 degrees | Sensor: 1/3-inch CMOS | VIEW LATEST PRICE | See Our Full Breakdown |
| Ford Transit backup camera | Compatible vehicles |
|---|---|
| Backup Camera for Ford Transit | Ford Transit 150, 250, and 350 (2014–2018) |
| Auto Wayfeng WF 170 CCD Car Re | — |
| Backup Camera for Ford Transit | Ford Transit 150, 250, 350, and HD (2015–2017); listing also states 2018–2019 cargo vans |
| Anpher Rear View 170° HD Night | Ford Transit 150, 250, 350, and 350HD (2015–2019) |
| Compatible with License Light | Ford Transit Connect MK6/MK7 (2000–2018 as listed) |
| LED Third Brake Light with Bac | Ford Transit 150, 250, 350, and 350 HD |
| High Mount Third Brake Light B | Ford Transit 150, 250, 350, and 350 HD |
| IP67 Waterproof Backup Camera | — |
| A-Premium Rear View Backup Cam | Transit 150, 250, 350, and 350 HD, low roof |
| Backup Camera for Ford Transit | — |
| Compatible for Ford Transit 15 | — |
| GreenYi Rear View Backup Camer | Ford Transit 150/250/350/350HD, 2015–2017; Transit Cargo Van, 2018–2019 |
| Backup Camera for Ford Transit | — |
| Backup Camera for Ford Transit | — |
More Details on Our Top Picks
Backup Camera for Ford Transit 150 250 350 (2014-2018), Waterproof Rear View, Night Vision, 720P AHD / 480P CVBS, Roof Mount
I’d put this roof-mount option first for owners of a 2014–2018 Transit whose display can accept AHD input: its selectable 720P AHD or 480P CVBS output gives more flexibility than the CVBS-only Auto Wayfeng WF 170. The 140-degree view is narrower than that camera’s 170-degree angle, but may suit drivers who prefer a less expanded view when judging the area directly behind the van. Six night-vision LEDs and a 10-meter cable support a roof-mounted installation, while waterproof construction is useful for a vehicle exposed to weather. The tradeoff is compatibility setup: switching to the higher-resolution mode requires cutting a control wire, and the stated fit covers only 2014–2018 models. I’d skip it if you need a plug-and-play, no-modification install.
Pros:- Offers 720P AHD and 480P CVBS output options.
- 10-meter cable supports roof mounting and longer routing paths.
- Six LEDs provide night-vision assistance.
- 140-degree view and waterproof construction suit everyday reversing in varied weather.
Cons:- Selecting AHD resolution requires cutting the white control wire.
- The 140-degree view is narrower than the 170-degree Auto Wayfeng WF 170 and other wide-angle options.
- Fit is limited to the listed 2014–2018 Transit models, and installation may call for professional help.
Best for: Owners of 2014–2018 Transit 150, 250, or 350 vans with an AHD-compatible display who want a roof-mounted camera and a long cable run.
Not ideal for: Drivers seeking the widest possible rear view, a straightforward wire-free resolution selection, or a camera for Transit years outside the listed range.
- Compatible vehicles:Ford Transit 150, 250, and 350 (2014–2018)
- Resolution:AHD 720P / CVBS 480P
- Viewing angle:140 degrees
- Night vision:Yes, 6 LEDs
- Installation type:Roof mount
- Cable length:10 meters
- Weather protection:Waterproof
Our verdict“Choose this camera for a 2014–2018 Transit with an AHD-compatible screen and a roof-mount plan, but not if you want the broadest view or a simpler resolution setup.”
Auto Wayfeng WF 170 CCD Car Reversing Rear View License Plate Backup Camera for Ford Transit Connect
The Auto Wayfeng WF 170 is the clearest fit here for a Ford Transit Connect owner who values a very broad rear view over newer video formats. Its 170-degree CCD lens covers more of the area behind the vehicle than the 140-degree roof camera in this roundup, which can help when backing out of tight spaces. It also supports NTSC and PAL and uses an RCA output, making it a practical match for compatible displays. That older-style signal is the main compromise: the listed 728 × 512 resolution and 520 TV lines do not offer the stated 720P capture of the Anpher camera. IPX68 protection is a useful weather specification, but the listing gives little long-term durability detail. I’d choose it for a compatible Connect setup, not as a universal Transit fit.
Pros:- 170-degree lens gives a broader rear view than the 140-degree roof-mount option.
- CCD sensor and 728 × 512 resolution are specified in the product data.
- NTSC and PAL support allows use with compatible video systems.
- IPX68 rating and stated operating range suit wet and cold-weather use.
Cons:- Listed specifically for Transit Connect rather than the full-size Transit lineup.
- Resolution is lower than the 720P options from Anpher and the roof-mount camera.
- Lens positioning may need manual adjustment, and long-term durability details are limited.
Best for: Transit Connect owners with an RCA-compatible NTSC or PAL monitor who want a fixed, wide rear view for parking.
Not ideal for: Owners of full-size Transit 150, 250, or 350 vans, or buyers who need 720P video or a documented vehicle-specific mount.
- Sensor type:1/4-inch CCD
- Resolution:728 × 512 pixels
- TV lines:520
- Viewing angle:170 degrees
- Waterproof grade:IPX68
- Operating temperature:-20°C to +80°C
- Power supply:12V DC
- Video output:RCA; NTSC/PAL support
Our verdict“Pick the WF 170 if you own a Transit Connect and want wide-angle RCA video, but look elsewhere for a full-size Transit fit or higher-resolution output.”
Backup Camera for Ford Transit 150/250/350/HD 2015-2017
This camera’s strongest case is its stated OEM interface compatibility and plug-and-play installation for specified Transit years. That makes it a more natural candidate for owners who want a vehicle-specific replacement than the Auto Wayfeng WF 170, which is aimed at Transit Connect and uses a general RCA connection. Its 170-degree view, infrared CMOS sensor, and 720P capture resolution also give it a useful balance of broad coverage and detail for reversing. The listing mentions 2015–2017 models and 2018–2019 cargo vans, so I’d verify the exact vehicle and connector before ordering rather than assume every Transit configuration is covered. It does not offer wireless connectivity, and the stated warranty has no duration here. Compared with Anpher’s camera, its fit story sounds more OEM-focused, while Anpher specifies 1080P.
Pros:- Product description specifies plug-and-play installation with OEM interface compatibility.
- 170-degree field of view covers a broad area behind the van.
- 720P capture and infrared CMOS sensor support reversing visibility.
- Waterproof construction is intended for use in harsh weather.
Cons:- Compatibility is limited to the listed Transit years and configurations.
- No wireless connection option is specified.
- Warranty duration and long-term durability details are not provided.
Best for: Owners of listed 2015–2017 Transit models or 2018–2019 cargo vans seeking a vehicle-specific, plug-and-play camera connection.
Not ideal for: Buyers who need wireless video, a clearly documented fit for other model years, or a stated 1080P capture specification.
- Compatible vehicles:Ford Transit 150, 250, 350, and HD (2015–2017); listing also states 2018–2019 cargo vans
- Optical sensor:CMOS infrared
- Field of view:170 degrees
- Video capture resolution:720P
- Connector:RCA
- Replacement part number:CK4Z-19G490-A
- Installation:Plug-and-play with OEM interface compatibility stated
- Weather protection:Waterproof
Our verdict“Choose this for a listed Transit with a compatible OEM interface when straightforward wiring matters more than wireless features or a stated 1080P specification.”
Anpher Rear View 170° HD Night Vision Backup Camera for Ford Transit 150/250/350/350HD (2015-2019)
Among these camera-only options, Anpher makes the strongest resolution claim: 1080P capture paired with a 170-degree view and night-vision support. That combination may appeal to Transit drivers who want broad coverage without settling for the 720P stated by the OEM-style alternative from B0CDBVTLD6. Its IP68 waterproof design and plug-and-play OEM-interface description also suit a vehicle-specific installation. The tradeoff is connector specificity: this model lists a 6-pin connection, so I’d confirm the van’s existing wiring before treating installation as simple. The product data also flags reversing lines whose alignment can vary with steering angle, which may affect how confidently a driver reads the guides. This is a better fit for buyers prioritizing the listed resolution than for those who need the most clearly established plug-and-play match.
Pros:- 1080P video capture is a higher stated resolution than the 720P alternatives in this group.
- 170-degree viewing angle covers a wide area behind the Transit.
- HD night vision and IP68 waterproofing address low-light and wet-weather use.
- Product description states plug-and-play installation with OEM interface compatibility.
Cons:- The 6-pin connector may not match every Transit configuration.
- Reversing-line alignment may vary with steering angle.
- Fit is restricted to the listed 2015–2019 model range.
Best for: Owners of 2015–2019 Transit 150, 250, 350, or 350HD vans who prioritize a stated 1080P camera and wide nighttime coverage.
Not ideal for: Buyers unable to verify a 6-pin connection, or drivers who rely on consistently aligned reversing guidelines.
- Compatible vehicles:Ford Transit 150, 250, 350, and 350HD (2015–2019)
- Video capture resolution:1080P
- Viewing angle:170 degrees
- Optical sensor:CMOS
- Connector:6-pin
- Monitor voltage:12 volts
- Installation type:Surface mount
Our verdict“Choose Anpher if 1080P and wide night coverage lead your priorities and your Transit matches its 6-pin connection; otherwise, the OEM-style alternative may be easier to match.”
Compatible with License Light Backup Camera Ford Transit Connect MK6 MK7 2000-2018 HD 1280x720p with 7-inch Monitor
Unlike the other picks here, this is a camera-and-monitor kit, so it suits a Transit Connect owner who needs a screen as well as rear visibility. The included 7-inch LCD removes the need to find a compatible display, while the license-light camera location gives the setup a vehicle-specific approach. Its 135-degree lens is narrower than the 170-degree cameras from Auto Wayfeng and Anpher, so it shows less of the area to either side; in return, it avoids asking buyers to source a separate monitor. The data lists 1280 × 720p for the camera description but also 480p CVBS capture, so I’d confirm the actual signal and screen compatibility before buying. Installation may require technical skill, and fit is stated for Transit Connect MK6/MK7, not every Transit.
Pros:- Includes a 7-inch LCD monitor rather than requiring a separate display.
- License-light camera design is aimed at a vehicle-specific installation.
- IP68 waterproof rating supports use in wet conditions.
- 135-degree wide-angle lens provides rear coverage for parking.
Cons:- The 135-degree view is narrower than the 170-degree cameras in this roundup.
- Product data lists both 1280 × 720p and 480p CVBS, so signal resolution should be confirmed.
- Installation may require technical skill, and compatibility is limited to the stated Transit Connect MK6/MK7 fit.
Best for: Transit Connect MK6 or MK7 owners who need both a backup camera and a dedicated 7-inch monitor in one kit.
Not ideal for: Full-size Transit owners, buyers who already have a compatible screen, or drivers who want a 170-degree view or a clearly consistent video-resolution specification.
- Compatible vehicles:Ford Transit Connect MK6/MK7 (2000–2018 as listed)
- Monitor size:7 inches
- Monitor voltage:12 volts
- Sensor type:CCD
- Lens angle:135 degrees
- Video resolution:1280 × 720p stated in description; 480p CVBS listed in specs
- Display technology:LCD
- Warranty:1 year
Our verdict“Choose this kit if your Transit Connect needs its own monitor and the listed fit is confirmed, but skip it if you already have a screen or need a wider view.”
LED Third Brake Light with Backup Camera for 2018-2019 Ford Transit 150/250/350/HD
This pick combines a replacement third brake light and backup camera, which makes it a practical match for owners replacing the whole high-mounted assembly on a 2018–2019 Transit. Its plug-and-play design may simplify the job, while the waterproof, dustproof housing suits a component exposed to road spray. Compared with the separate camera-only A-Premium unit for 2020–2022 low-roof models, this option adds the brake-light assembly but covers different model years. The listing gives little detail about camera resolution, viewing angle, or display connections, so I would verify those against the van before ordering. Professional installation is also recommended, making this a less certain choice for buyers expecting a guaranteed quick DIY swap.
Pros:- Combines the third brake light and backup camera in one replacement assembly
- Plug-and-play installation is specified
- Waterproof and dustproof construction suits exterior mounting
- LED brake light provides high brightness
Cons:- Camera resolution and field of view are not specified
- Professional installation is recommended
- Compatibility is listed for 2018–2019 Transit models, with little detail for other configurations
Best for: 2018–2019 Transit 150, 250, 350, or 350 HD owners replacing the high-mounted brake-light assembly and camera together
Not ideal for: Owners who need published camera resolution, viewing angle, or connector details before confirming compatibility with their display
- Model years:2018–2019
- Compatible vehicles:Ford Transit 150, 250, 350, and 350 HD
- Position:Center
- Light source:LED
- Material:ABS plastic
- Lens color:Red
- Additional features:Waterproof and dustproof
- Part numbers:JK4Z13A613AA, JK4Z13A613AD
Our verdict“Choose this integrated assembly if your 2018–2019 Transit needs both a high-mounted brake light and backup camera replaced, but confirm camera connections and fit first.”
High Mount Third Brake Light Backup Camera for Ford Transit 150 250 350 350HD 2014-2018
The standout here is its 170-degree field of view, paired with 12 infrared lights for reversing in dim conditions. That broad view can help when positioning a long Transit, though a wide image may show more surrounding area rather than prioritizing fine detail. Unlike the 2012–2015 IP67 camera in this lineup, this assembly lists compatibility through 2018 and specifies RCA video output with NTSC display support. That connection requirement matters: buyers should check the existing screen or head unit before ordering. The product description calls installation easy and includes cables, but it also advises testing with the head unit, so this is a better fit for someone comfortable confirming video compatibility than for a buyer expecting a guaranteed direct connection.
Pros:- 170-degree viewing angle covers a broad area behind the van
- 12 infrared lights support visibility in low light
- IP67 waterproof rating is suited to exterior use
- Includes cables and lists RCA connectivity
Cons:- Requires an RCA video input and NTSC display support
- Head-unit compatibility may need testing before installation
- Listed video capture resolution is 580p rather than the 720p specified for the 2012–2015 camera
Best for: 2014–2018 Transit owners who want a wide rear view and have an RCA-input display that supports NTSC video
Not ideal for: Drivers with factory displays lacking compatible RCA input or those who want a camera with explicitly listed 720p resolution
- Compatible model years:2014–2018
- Compatible vehicles:Ford Transit 150, 250, 350, and 350 HD
- Optical sensor:CMOS, 1/3 inch
- Viewing angle:170 degrees
- Video capture resolution:580p
- Night vision:12 infrared lights
- Connector:RCA
- Warranty:12 months
Our verdict“Pick this for broad rear coverage on a compatible 2014–2018 Transit display, but verify RCA and NTSC support before committing.”
IP67 Waterproof Backup Camera for Ford Transit 2012-2015
For a 2012–2015 Transit, this camera pairs a stated 720p image with a 140-degree view and IP67 protection. That combination gives buyers concrete image and weather specifications, unlike the 2018–2019 integrated brake-light option, whose camera resolution and field of view are not provided. Its high-mount third brake-light position is tailored to the Transit installation, while the wired connection favors a fixed setup over flexible placement. The 140-degree angle is narrower than the 170-degree views listed for the 2014–2018 CMOS unit and the 2015–2019 camera, so it may show less of the sides behind a wide van. Year fit is the deciding factor; it is not a substitute for a newer-model camera.
Pros:- 720p resolution is specified
- 140-degree viewing angle offers broad rear coverage
- IP67 protection and night vision suit outdoor use
- High-mount placement is designed for the Transit
Cons:- Compatibility is limited to 2012–2015 Transit models
- Wired connection can restrict installation flexibility
- No adjustable camera angle is specified
Best for: Owners of 2012–2015 Ford Transit vans seeking a wired, high-mounted camera with specified 720p imaging and weather protection
Not ideal for: Owners of 2016 or newer Transits, or drivers who prioritize a wider-than-140-degree view or adjustable camera positioning
- Compatibility:Ford Transit 2012–2015
- Resolution:720p
- Viewing angle:140 degrees
- Night vision:Yes
- Mounting position:High-mount third brake light
- Connection type:Wired
- Dimensions:1 x 1 x 1 inch
Our verdict“This is a sensible fit for a 2012–2015 Transit owner who values stated 720p imaging and weather protection over a wider viewing angle.”
A-Premium Rear View Backup Camera for Ford Transit 2020-2022
This is the lineup’s clearest match for a 2020–2022 low-roof Transit: it is described as an OE replacement and covers Transit 150, 250, 350, and 350 HD models. Its quick installation without special tools may appeal to owners replacing a failed camera rather than adding a new camera-and-screen system. Compared with the 2018–2019 brake-light camera, this A-Premium option is a camera-only replacement for newer vans, not an integrated third brake-light assembly. The tradeoff is limited camera detail: the listing does not specify resolution, field of view, night vision, or waterproof rating. Its year and low-roof restriction also make fitment checks especially important; buyers with high-roof vans should not assume compatibility from the model name alone.
Pros:- Specified fit for 2020–2022 Transit models with low roofs
- OE replacement positioning helps target a like-for-like camera swap
- Installation is described as quick and requires no special tools
- Two-year unlimited-mileage guarantee is listed
Cons:- Compatibility is limited to low-roof configurations
- Resolution, viewing angle, and night-vision details are not provided
- Does not include a front camera or a third brake-light assembly
Best for: Owners of 2020–2022 low-roof Transit 150, 250, 350, or 350 HD models replacing the rear camera with an OE-style part
Not ideal for: High-roof Transit owners, drivers of other model years, or buyers who need published resolution, viewing-angle, or weather-resistance specifications
- Model years:2020–2022
- Compatible vehicles:Transit 150, 250, 350, and 350 HD, low roof
- Part numbers:FO1960188, LK4Z19G490B, LK4Z19G490G, LK4Z19G490K, PAC491
- Installation:Quick installation; no special tools required
- Weight:1.76 ounces
- Dimensions:2.76 x 2.76 x 2.76 inches
- Warranty:Two-year unlimited-mileage guarantee
Our verdict“Choose this for a like-for-like rear camera replacement on a confirmed 2020–2022 low-roof Transit, not for a high-roof van or a feature-led camera upgrade.”
Backup Camera for Ford Transit 150 250 350 350HD (2015-2017, 2018-2019)
This camera targets a broad run of 2015–2019 Transit models, including 2018–2019 cargo vans, and pairs plug-and-play installation with a 170-degree lens and night vision. It may suit an owner replacing a failed factory camera who wants to retain the existing display, rather than buying a full brake-light camera assembly like the 2018–2019 LED option. The listing names replacement part number CK4Z-19G490-A, which gives buyers a useful fitment check. Its main weakness is the lack of a stated waterproof rating, especially when compared with the IP67-rated 2012–2015 camera. The one-year warranty is also shorter than the 12-month warranty listed for the high-mount 2014–2018 camera only insofar as both are one year; buyers should focus on confirmed fit and connection details.
Pros:- 170-degree lens covers a broad area behind the van
- Night vision is included
- Plug-and-play installation is specified
- Replacement part number supports fitment cross-checking
Cons:- No waterproof rating is specified
- Compatibility is limited to the listed Transit years and configurations
- One-year warranty is specified
Best for: 2015–2019 Transit owners replacing a camera associated with CK4Z-19G490-A who want a wide view and plug-and-play installation
Not ideal for: Buyers who need a published waterproof rating, or owners whose vehicle is outside the listed model years and configurations
- Compatible models:Transit 150, 250, 350, and 350 HD (2015–2017); Transit Cargo Van (2018–2019)
- Lens angle:170 degrees
- Night vision:Yes
- Replacement part number:CK4Z-19G490-A / CK4Z19G490A
- Dimensions:2.4 x 2.4 x 2.4 inches
- Installation:Plug-and-play
- Warranty:1 year
Our verdict“This is a strong candidate for a compatible 2015–2019 Transit camera swap when wide coverage and plug-and-play installation matter more than a documented waterproof rating.”
Compatible for Ford Transit 150/250/350/350 HD 2015-2020 Brake Light Backup Camera with 7-inch Clip-on Mirror Monitor
This is the clearest choice for Transit owners who need both a camera and a way to view it: the kit pairs a 7-inch clip-on monitor with a brake-light camera, rather than requiring an existing compatible display. Its stated 170-degree lens offers broader coverage than GreenYi’s 130-degree view, which can help when judging the area across a wide van rear. The tradeoff is that a large monitor takes more room in the cab, and the listing says professional installation may be needed for the best setup. Its listed 2015–2020 fitment is broader than the 2014–2018 range of the 720p camera from B0FV7L4ND6, but buyers should still confirm their exact Transit configuration before ordering. I’d choose this kit for an all-in-one setup, not for a discreet camera-only replacement.
Pros:- Includes a 7-inch clip-on mirror monitor, avoiding the need to source a separate display
- 170-degree lens gives a wider stated field of view than GreenYi’s 130-degree camera
- Lists night vision and waterproof construction for low-light and wet-weather use
- 720p video capture resolution is specified
Cons:- The large clip-on monitor may be intrusive compared with a camera-only replacement
- Professional installation may be needed for a clean, reliable setup
- Compatibility is limited to the listed 2015–2020 Transit years and should be checked against the exact vehicle
Best for: Transit drivers from the listed model years who need a camera and a dedicated, large in-cab display in one kit.
Not ideal for: Owners who already have a compatible screen or want a small, low-profile display; this kit includes a sizeable 7-inch clip-on monitor.
- Compatible model years:Ford Transit 150/250/350/350 HD, 2015–2020
- Monitor size:7 inches
- Monitor voltage:12 volts
- Lens field of view:170 degrees
- Sensor:CMOS
- Video capture resolution:720p
- Display technology:LED
- Warranty:1 year
Our verdict“Choose this kit if you want a wide-angle Transit camera and its own large monitor, and skip it if you already have a display or prefer a minimal cab setup.”
GreenYi Rear View Backup Camera for Ford Transit 150/250/350/350HD 2015-2019
GreenYi’s main appeal is its original-mount, plug-and-play installation, which makes it a more natural pick for owners replacing a camera at the factory location than the complete monitor kit B07DDKB8PD. The supplied details also specify IP68 waterproof housing and star night vision, useful for a van that works outdoors or reverses in dim lots. Its 130-degree view is narrower than that kit’s stated 170 degrees, so it may show less of the area beside the rear corners. Although the listing includes a 7-inch screen size, it does not clearly establish whether a monitor is included; check the package contents and display compatibility before buying. This is a fit-and-installation-led option, not the strongest choice for shoppers prioritizing the widest stated view.
Pros:- Original-mount, plug-and-play installation is aimed at a factory-location replacement
- IP68-rated housing is specified for water protection
- Star night vision is listed for dim reversing conditions
- Fitment covers specified Transit passenger and cargo van years from 2015–2019
Cons:- Its 130-degree view is narrower than the 170-degree views listed for B07DDKB8PD and B0CJFVCSRQ
- The product details do not clearly confirm whether a monitor is included
- Some buyers may encounter installation issues despite the plug-and-play description
Best for: Transit owners with a compatible display who want a camera intended for the original mounting location and a plug-and-play installation approach.
Not ideal for: Drivers who need a clearly confirmed complete camera-and-monitor kit or want the broadest stated viewing angle; the listing leaves monitor inclusion unclear and specifies 130 degrees.
- Compatible vehicles:Ford Transit 150/250/350/350HD, 2015–2017; Transit Cargo Van, 2018–2019
- Listed screen size:7 inches
- Voltage:12 volts DC
- Lens field of view:130 degrees
- Video capture resolution:960 × 480p
- Sensor:CMOS
- Installation:Original mounting, plug and play
- Warranty:1 year manufacturer warranty
Our verdict“Pick GreenYi for a factory-location-style replacement with stated IP68 protection, but confirm the screen arrangement and accept a narrower view than the 170-degree alternatives.”
Backup Camera for Ford Transit 2014-2018 with 140° Wide Angle, IP67 Waterproof, Night Vision, 720P HD
This camera is the straightforward pick for buyers who want a defined 720p image and a wired connection, without adding a separate monitor kit to the purchase. Its 140-degree field of view lands between GreenYi’s 130 degrees and the 170 degrees stated by B07DDKB8PD, giving buyers a middle ground between coverage and a more restrained view. The listing also gives an IP67 rating, night vision, and an operating range of −20°C to +60°C, details that help frame its weather use. Unlike the all-in-one B07DDKB8PD, this is a camera component, so the buyer needs a compatible display and must account for the wired installation. Its 2014–2018 fitment may suit some earlier Transits, but it does not cover later model years.
Pros:- 720p HD resolution is explicitly specified
- 140-degree field of view offers a middle ground between GreenYi’s 130 degrees and 170-degree alternatives
- IP67 waterproof and dustproof rating is listed
- Operating temperature range is specified as −20°C to +60°C
Cons:- A compatible display is needed; no monitor is specified as included
- Wired installation offers less placement flexibility than a wireless setup
- Fitment is limited to the listed 2014–2018 Transit years
Best for: Owners of 2014–2018 Ford Transit vans who need a wired replacement camera with specified 720p resolution and already have a compatible screen.
Not ideal for: Drivers seeking a complete monitor-and-camera package or a 2019-or-newer fit; this listing is camera-only and specifies 2014–2018 compatibility.
- Compatibility:Ford Transit, 2014–2018
- Field of view:140 degrees
- Resolution:720p HD
- Night vision:Yes
- Connector:Proprietary Ford Transit connector
- Sensor:CMOS, 1/3 inch
- Operating temperature:−20°C to +60°C
Our verdict“Choose this camera for a specified 720p wired replacement on a 2014–2018 Transit, provided you already have a compatible display.”
Backup Camera for Ford Transit 150/250/350/HD 2015-2017
If rear coverage is the main priority and a display is already in place, this camera’s stated 170-degree field of view matches the widest figure in this group. It is a camera-only option, unlike B07DDKB8PD, so it avoids adding another monitor but leaves screen compatibility to the buyer. The listing describes surface-mount, plug-and-play installation and waterproof construction, which may suit a replacement at an accessible mounting point. Its resolution entry is simply “350,” however, and does not clearly describe a video format or standard; buyers who need a well-defined image specification may prefer the explicit 720p camera B0FV7L4ND6. Fitment is also narrower for passenger models, covering 2015–2017, with 2018–2019 called out only for Cargo Van.
Pros:- 170-degree field of view is among the widest stated in this group
- Plug-and-play installation is listed
- Waterproof construction and night vision are specified
- Compatibility includes 2015–2017 models and 2018–2019 Cargo Van
Cons:- No monitor is included, so a compatible display is required
- The listed video resolution of “350” is unclear and does not establish a familiar HD format
- Passenger Transit fitment is limited to 2015–2017
Best for: Transit owners with a compatible display who want a camera-only replacement and prioritize a wide stated rear view.
Not ideal for: Buyers who need a monitor included, a clearly specified HD resolution, or fitment for 2018–2019 non-cargo Transit models.
- Compatibility:Ford Transit 150/250/350/HD, 2015–2017; Cargo Van, 2018–2019
- Field of view:170 degrees
- Sensor:1/3-inch CMOS
- Lens:Glass-plastic hybrid
- Installation:Surface mount, plug and play
- Video resolution listing:350
- Display:LCD or LED compatible display required; not included
Our verdict“Choose this camera-only option for its wide stated view if your display is compatible, but favor B0FV7L4ND6 if a clearly stated 720p resolution matters more.”
How We Picked
I ranked these 14 cameras by practical fit for a Ford Transit, not by headline resolution alone. The main criteria were stated model-year and vehicle coverage, mounting style, whether a monitor is included, signal-format flexibility, and features relevant to reversing in poor weather or low light. I gave extra weight to listings that make a clear distinction between a replacement camera and a camera-plus-monitor system, since those choices affect installation and compatibility.
When products cover similar years, I separated them by their intended use rather than treating near-duplicate titles as proof of equivalent hardware. A broader year range does not automatically outrank a narrower one: connector, body configuration, and original equipment can change within a model generation. The ranking favors options with a clear role and useful setup flexibility, while noting where a buyer needs to verify fit or accept extra installation work.
Factors to Consider When Choosing Ford Transit Backup Cameras
Before choosing a camera, I would match the van and the display system on paper. Ford Transit listings can cover different body styles, generations, and mounting locations, so the camera title alone is not enough to confirm a fit. These checks help avoid buying a camera that has the right general description but the wrong connector, screen signal, or physical mounting point.
Match the van’s year, model, and body configuration
Start with the Transit’s model year and exact model, then check whether the listing names 150, 250, 350, or 350HD where relevant. A Transit Connect is a distinct fitment category, so a Connect camera should not be treated as a substitute for a full-size Transit camera. Model-year ranges can overlap while still using different connectors or mounting hardware. If the van has an existing camera, compare its connector and housing with the replacement listing or ask the seller for a fitment check. This extra step is especially useful for vans with fleet modifications or a prior aftermarket camera. Choosing by vehicle details first narrows the field more reliably than choosing by resolution.
Choose a mounting location that matches the van
Roof-mount, third-brake-light, and license-light cameras solve different installation problems. A high-mounted camera can give a useful view behind a tall van, but replacing the brake-light assembly may involve more work than swapping a camera near the plate. License-area mounting may be more accessible, yet can produce a lower view that is less helpful when judging objects close to the bumper. Check whether the camera is meant to replace an original part or attach using existing hardware. Also confirm that the mounting position leaves the lens unobstructed by doors, trim, or accessories. A camera with appealing specifications can be a poor choice if its position does not suit the van’s rear layout.
Confirm the camera signal works with the display
AHD and CVBS are different video signal formats, and a screen that accepts one may not accept the other. A selectable-format camera can offer flexibility, but it still needs to be set to a mode supported by the connected monitor. Before ordering, identify whether the van uses an existing factory screen, an aftermarket head unit, a clip-on mirror display, or a separate monitor. Bundled 7-inch monitor kits can simplify component matching, though they introduce another screen to mount and power. Buyers who already have a working display may prefer a camera-only option, provided the signal and wiring match. Treat “HD” as a description, not proof of display compatibility.
Decide whether you want a camera-only part or a full kit
Camera-only replacements make the most sense when the van already has a compatible screen and wiring. A monitor bundle may be easier for a first installation because the camera and display are sold together, but it can require routing new cable and finding a suitable place in the cab. A clip-on mirror monitor changes the driving view less than adding a separate dashboard screen, while a standalone display may be easier to position for visibility. Check what the package includes rather than assuming that a camera listing contains the monitor, harness, or adapters shown in an image. If the van is shared among drivers, think about whether an added screen could block sightlines or become a distraction. The simplest package is the one that fits the equipment already in the vehicle.
Read weather and night-vision claims in context
Waterproof ratings such as IP67 describe protection under specified test conditions; they do not make a camera immune to damaged seals, pressure washing at close range, or poor installation. Night-vision features can help in dim areas, but the actual view also depends on lens condition, available light, and the display. Wide-angle coverage shows more of the area behind the van, though it can make distances harder to judge near the edges. A 140° or 170° claim should be weighed alongside mounting height and the driver’s need to see close obstacles. For work vans used in rain or frequent loading, favor secure housing and protected wiring rather than relying on a rating alone. Keep the lens clean and inspect the cable entry points as part of routine maintenance.
Plan the installation before paying for extra features
Camera replacement can involve removing trim, accessing the brake-light assembly, or routing a video cable from the rear to the cab. A feature-rich camera may not be a sensible upgrade if installation requires more labor or adapters than the van’s current system can support. Check whether the camera activates through the reverse-light circuit or needs a separate trigger connection, and confirm the wiring instructions for the exact kit. Buyers with limited installation experience may value a bundled monitor and clearer mounting approach, while fleet owners may prioritize repeatable fit across several vans. If the listing leaves connector type or wiring unclear, seek confirmation before ordering. Paying for additional resolution or viewing angle has little benefit if the camera cannot be installed cleanly or displayed correctly.
Frequently Asked Questions
Will a Ford Transit backup camera listed for 2015–2019 fit every Transit from those years?
No. A year range is a starting point, not a guarantee that every body configuration uses the same camera, connector, or mounting assembly. Check whether the listing specifies the Transit 150, 250, 350, or 350HD, and compare the original camera’s connector and shape. Prior owner modifications can also change what is installed. If the listing does not identify those details, confirm fitment with the seller before ordering.
Can I connect an AHD camera to my Transit’s existing screen?
Only if the screen accepts the camera’s signal format and the wiring is compatible. Some replacement cameras offer AHD and CVBS modes, but the chosen mode must match the display input. Identify the screen or head unit model and check its camera-input specifications rather than relying on a general “HD” label. If the existing display is CVBS-only, an AHD-only camera may not show an image without a compatible interface. A camera-and-monitor kit avoids some matching work, but it adds a separate display.
Should I choose a brake-light camera or a license-area camera?
Choose based on the existing mounting point, the view you need, and how much installation work you want to take on. A brake-light camera sits higher, which can help show more of the area behind a tall van, but replacing that assembly may require extra disassembly. A license-light camera can suit a Transit Connect or a setup designed around that location, but its lower position may leave a different view close to the bumper. Confirm the replacement part matches the van before choosing based on camera angle alone. The best location is the one that fits the vehicle and gives a usable view for your reversing conditions.
Is a camera kit with a 7-inch monitor a better choice than a camera-only replacement?
It is a better fit when the van has no usable display or when you want camera and screen components sold as a set. A camera-only replacement can be simpler if the factory or aftermarket display already works and accepts the camera’s signal. The monitor kit adds a screen to place and power, and its size may affect the cab layout or driver sightlines. Before choosing, check what cables and mounting hardware the package includes. The key tradeoff is fewer display-matching decisions versus additional cabin equipment and installation steps.
Will a waterproof or night-vision camera show everything behind a long Transit?
No camera can remove every blind area, and those features do not replace mirrors or a direct safety check. Waterproof construction helps protect the camera under the conditions covered by its rating, while night-vision capability can improve visibility in low light; neither guarantees a clear picture in every setting. Lens dirt, glare, mounting angle, and the display all affect what the driver sees. A wide-angle lens may show more surroundings but can make distance judgment less intuitive. Use the camera as an aid, especially when reversing into tight spaces or around pedestrians.
Conclusion
For the broadest mix of fit flexibility and useful features, I would start with the 2014–2018 roof-mount AHD/CVBS camera as the best overall pick, after confirming the display format. The best value is a compatible camera-only replacement when the van already has a working screen, since it avoids adding equipment that may not be needed. For a more integrated setup, my best premium-style choice is a third-brake-light camera paired with a monitor, while the best option for beginners is a bundled camera-and-monitor kit that reduces component matching. Transit Connect owners should focus on the license-light or plate-mount Connect-specific options, not full-size Transit listings. For newer vans, the A-Premium 2020–2022 camera is the targeted pick; whatever the choice, verify year, body version, connector, mount, and display compatibility before buying.
Halloween Picks
halloween
As an affiliate, we earn on qualifying purchases.
