YouTuber Delton Adams built a working Lego model based on an antique hit-and-miss engine. The model uses vacuum rather than combustion, with an inverted cam-and-rocker valve arrangement and a fly-ball governor. Adams says it produces 0.12 watts, or about 1.5 “studpower.”
YouTuber Delton Adams has built a working Lego model of an antique hit-and-miss engine, adapting the early internal-combustion design to operate with vacuum instead of fuel and ignition. The project recreates several mechanical features of the historical engine, including its governor, while producing a modest 0.12 watts, according to the report by The Drive.
The name hit-and-miss describes how the original engines regulated speed: a governor allowed ignition when the engine slowed to a set point, then kept the exhaust valve open so the engine could cycle without firing while it ran faster. These engines were used mainly as stationary power sources in the early 20th century and had largely fallen out of common use by the 1930s, according to The Drive.
Adams’s model does not burn fuel. The Lego engine runs by pumping air in and drawing it out, making its operating cycle different from the four-stroke design he modeled. In his video, Adams explains that trying to reproduce the original four-stroke action under vacuum could pull the piston out of position. The model instead uses a two-stroke vacuum cycle.
To adapt the valve mechanism, Adams moves the camshaft out of the way during the cycle and uses an inverted cam-and-rocker arrangement with a spring to operate the valve against vacuum pressure. The governor is a fly-ball mechanism, which uses centrifugal force. Other working parts, including the crankshaft, piston, connecting rod and cylinder head, are also made from Lego components, The Drive reports.
An Old Engine Rebuilt in Bricks
The model offers a hands-on demonstration of a mechanical design that is now uncommon outside historical displays and specialist hobby communities. Its governor and valve arrangement show how an engine could control its speed by deciding when to fire, rather than by delivering power on every cycle.
The project also illustrates the difference between copying an engine’s appearance and reproducing its operation. Because Adams’s version uses vacuum rather than combustion, he had to alter the mechanism to keep it working. The result is a functional model, not a full-scale replica of the original engine’s power source or operating cycle.
Lego antique hit-and-miss engine kit
As an affiliate, we earn on qualifying purchases.
As an affiliate, we earn on qualifying purchases.
How Hit-and-Miss Engines Worked
Hit-and-miss engines were used in the early 20th century, often to provide power at a fixed location. Their governing system let the engine fire only when its speed dropped. At higher speeds, the governor held the exhaust valve open, allowing the engine to pass through cycles without ignition. The arrangement accounts for the name: the engine would “hit” when firing and “miss” when it did not.
The real engine Adams used as a model was a four-stroke design, though hit-and-miss engines also existed in two-stroke versions, The Drive reports. Lego vacuum engines use air movement rather than fuel combustion, so Adams modified the cam and valve setup to work with that different process. His model retains the period-style fly-ball governor while changing how the valve is operated.
“The model is a four-stroke engine, but Lego vacuum operation is a two-stroke cycle.”
— Delton Adams, in the video described by The Drive
As an affiliate, we earn on qualifying purchases.
Limits of the Reported Build
The available report does not specify the model’s dimensions, the vacuum source, how long it can run, or how its 0.12-watt output was measured. It also does not provide independent testing of the power figure. The source describes the model as working, but gives no runtime or performance comparison with other Lego engines.
The report does not state when Adams published the video or whether he plans further revisions. The model’s vacuum operation also means its performance should not be treated as a direct measure of a historical hit-and-miss engine, which used combustion and ignition.
As an affiliate, we earn on qualifying purchases.
What the Video Shows Next
The report points readers to Adams’s video, titled “The Most REALISTIC LEGO Hit-&-Miss Engine!”, for a demonstration of the mechanism. No further build, testing schedule or follow-up from Adams is identified in the source. Any additional performance details or design changes would depend on further information from the builder.
As an affiliate, we earn on qualifying purchases.
Key Questions
What is a hit-and-miss engine?
It is an engine that regulates speed by firing at a set threshold and allowing cycles without ignition when running faster. A governor controls the exhaust valve during those non-firing cycles.
Does Adams’s Lego engine run on combustion?
No. The model uses vacuum power, with air pumped in and drawn out. It does not reproduce the fuel-burning process of a historical hit-and-miss engine.
How much power does the Lego model produce?
The Drive reports an output of 0.12 watts, described as about 1.5 “studpower.” The report does not detail how that figure was measured.
Why did Adams change the valve mechanism?
Adams says a four-stroke arrangement could pull the piston out of position under vacuum. He used an inverted cam and rocker with a spring to make the valve work with the model’s two-stroke vacuum cycle.
